Forklift Fuel Tank - Nearly all fuel tanks are fabricated; however various fuel tanks are made by expert craftspeople. Restored tanks or custom tanks could be used on automotive, tractors, motorcycles and aircraft.
There are a series of specific requirements to be followed when making fuel tanks. Typically, the craftsman sets up a mockup so as to determine the precise shape and size of the tank. This is normally performed using foam board. Afterward, design concerns are dealt with, including where the seams, drain, outlet, baffles and fluid level indicator would go. The craftsman needs to find out the alloy, thickness and temper of the metallic sheet he would utilize in order to construct the tank. When the metal sheet is cut into the shapes needed, many parts are bent in order to make the basic shell and or the ends and baffles used for the fuel tank.
A lot of baffles in aircraft and racecars contain "lightening" holes. These flanged holes have two purposes. They add strength to the baffles while reducing the weight of the tank. Openings are added toward the ends of construction for the fuel pickup, the filler neck, the fluid-level sending unit and the drain. Occasionally these holes are added when the fabrication method is finish, other times they are made on the flat shell.
The ends and the baffles are afterward riveted in position. Frequently, the rivet heads are brazed or soldered to be able to avoid tank leakage. Ends can next be hemmed in and flanged and sealed, or brazed, or soldered with an epoxy kind of sealant, or the ends can even be flanged and then welded. After the soldering, brazing and welding has been finished, the fuel tank is checked for leaks.
